| Model | WKT-V6 |
| Temperature Control Accuracy | ±0.1℃ |
| Ramp Range | 40-300℃ |
| Ramp Rate | 30℃/min (40-200℃)
10℃/min（200-300℃） |
| Cooling Rate | 10℃/min |
| Flow Range | 0-200ml/min（0.1Mpa） |
| Flow Accuracy | 0.1ml/min |
| Sample Vial Size | 10ml（5ml、20mlOptional） |
| Sample Introduction | Automatic sampling, automatic needle withdrawal, automatic measurement |
| Sample Capacity | 12 standard stations, optionally expandable to 24 |
| Special Functions | Data storage, curve analysis, electronic flow control, USB update |
| Operation | 7-inch color capacitive touchscreen |
| Heated Line | 12V 5W |
| Carrier Gas Inlet | 3.2mm Corrosion-Resistant Tubing |
| Carrier Gas System | Built-in high-purity air generator (external nitrogen, oxygen and other gas sources can be connected) |
| Communication | Data communication with the moisture analyzer; local system upgrade via USB drive |
| Ambient Temperature | 5-40°C |
| Ambient Humidity | <65%; the drier the humidity, the more stable the instrument |
| Unit Dimensions | 350*250*220mm |
| Power Supply | 220V 50HZ，150W |
| Optional | Sample boat pre-heating unit, automatic sampling unit |
| Weight | 9Kg |
