DSC Differential Scanning Calorimeter

Home > Products > Thermal Analyzers > DSC Differential Scanning Calorimeter
Overview Product Filter Related Services Related Products
Need Help? Get a Quote

Product Filter

Filter Options
Instrument Comparison

Compare

Model & Name
Test Parameters
Temperature Control Range
Cooling Method
Automation Options
WKT-RC200R Differential Scanning Calorimeter for Melting Point WKT-RC200R Differential Scanning Calorimeter for Melting Point
Melting Point
Room temperature–600 ℃
Air-cooled
Heating scan, isothermal scan
Material No.: 2022098898011
Detailed Specifications
Temperature RangeRoom temperature–600 ℃ (air-cooled)
Temperature Resolution0.01℃
Temperature Stability±0.01℃
Temperature Repeatability±0.1℃
Ramp Rate0.1～100℃/min
Stabilization TimeProgram Setting
Temperature ControlPID temperature control with automatic ramping and holding (fully automatic program control)
DSC Range0～±600mW
DSC Resolution0.01uW
DSC Sensitivity0.001mW
Operating PowerAC220V/50Hz or custom
Atmosphere GasNitrogen, oxygen (automatic instrument switching)
Gas Flow0-300mL/min
Gas Pressure0.2MPa
Display24-bit color, 7-inch LCD touchscreen display
Data InterfaceStandard USB interface
StandardSupplied with reference materials (indium, tin) so users can calibrate the temperature themselves
Scan ModesHeating Scan, Cooling Scan, Isothermal Scan
Inquire Now
WKT-RC200Y Differential Scanning Calorimeter for Oxidation Induction Time WKT-RC200Y Differential Scanning Calorimeter for Oxidation Induction Time
Oxidation Induction Time (OIT)
Room temperature–600 ℃
Air-cooled
Heating scan, isothermal scan
Material No.: 2022098898012
Detailed Specifications
Temperature RangeRoom temperature–600 ℃ (air-cooled)
Temperature Resolution0.01℃
Temperature Stability±0.01℃
Temperature Repeatability±0.1℃
Ramp Rate0.1～100℃/min
Stabilization TimeProgram Setting
Temperature ControlPID temperature control with automatic ramping and holding (fully automatic program control)
DSC Range0～±600mW
DSC Resolution0.01uW
DSC Sensitivity0.001mW
Operating PowerAC220V/50Hz or custom
Atmosphere GasNitrogen, oxygen (automatic instrument switching)
Gas Flow0-300mL/min
Gas Pressure0.2MPa
Display24-bit color, 7-inch LCD touchscreen display
Data InterfaceStandard USB interface
StandardSupplied with reference materials (indium, tin) so users can calibrate the temperature themselves
Scan ModesHeating Scan, Cooling Scan, Isothermal Scan
Inquire Now
WKT-RC200A Differential Scanning Calorimeter Multi-Parameter WKT-RC200A Differential Scanning Calorimeter Multi-Parameter
Oxidation Induction Time (OIT), Glass Transition Temperature (Tg), Melting Point, Melting, Enthalpy Change, Phase Transition, Cold Crystallization, Crystallization, Product Stability, Degree of Cure, Degree of Crosslinking, Heat of Reaction
Room temperature–600 ℃
Air-cooled
Heating scan, isothermal scan
Material No.: 2022098898013
Detailed Specifications
Temperature RangeRoom temperature–600 ℃ (air-cooled)
Temperature Resolution0.01℃
Temperature Stability±0.01℃
Temperature Repeatability±0.1℃
Ramp Rate0.1～100℃/min
Stabilization TimeProgram Setting
Temperature ControlPID temperature control with automatic ramping and holding (fully automatic program control)
DSC Range0～±600mW
DSC Resolution0.01uW
DSC Sensitivity0.001mW
Operating PowerAC220V/50Hz or custom
Atmosphere GasNitrogen, oxygen (automatic instrument switching)
Gas Flow0-300mL/min
Gas Pressure0.2MPa
Display24-bit color, 7-inch LCD touchscreen display
Data InterfaceStandard USB interface
StandardSupplied with reference materials (indium, tin) so users can calibrate the temperature themselves
Scan ModesHeating Scan, Cooling Scan, Isothermal Scan
Inquire Now
WKT-RC600L DSC Differential Scanning Calorimeter Semiconductor Cooling WKT-RC600L DSC Differential Scanning Calorimeter Semiconductor Cooling
Oxidation Induction Time (OIT), Glass Transition Temperature (Tg), Melting Point, Melting, Enthalpy Change, Phase Transition, Cold Crystallization, Crystallization, Product Stability, Degree of Cure, Degree of Crosslinking, Specific Heat Capacity, Heat of Reaction
-40℃-600℃
Semiconductor Cooling
Heating Scan, Cooling Scan, Isothermal Scan
Material No.: 2022098898015
Detailed Specifications
Temperature Range-40°C~600°C (Air Cooled)
Temperature Resolution0.001℃
Temperature Stability±0.01℃
Temperature Repeatability±0.1℃
Ramp Rate0.1～100℃/min
Stabilization TimeProgram Setting
Temperature ControlPID Temperature Control with Heating, Isothermal Holding and Cooling (Fully Automatic Program Control)
DSC Range0～±800mW
DSC Resolution0.01uW
DSC Sensitivity0.001mW
Operating PowerAC220V/50Hz or custom
Atmosphere GasNitrogen, oxygen (automatic instrument switching)
Gas Flow0-300mL/min
Gas Pressure0.2MPa
Display24-bit color, 7-inch LCD touchscreen display
Data InterfaceStandard USB interface
StandardSupplied with Reference Materials (Indium, Tin, Lead) for User Temperature Calibration
Scan ModesHeating Scan, Cooling Scan, Isothermal Scan
Inquire Now
WKT-RC600 DSC Differential Scanning Calorimeter Ambient WKT-RC600 DSC Differential Scanning Calorimeter Ambient
Oxidation Induction Time (OIT), Glass Transition Temperature (Tg), Melting Point, Melting, Enthalpy Change, Phase Transition, Cold Crystallization, Crystallization, Product Stability, Degree of Cure, Degree of Crosslinking, Specific Heat Capacity, Heat of Reaction
Room temperature–600 ℃
Air-cooled
Heating Scan, Cooling Scan, Isothermal Scan
Material No.: 2022098898016
Detailed Specifications
Temperature RangeRoom temperature–600 ℃ (air-cooled)
Temperature Resolution0.001℃
Temperature Stability±0.01℃
Temperature Repeatability±0.1℃
Ramp Rate0.1～100℃/min
Stabilization TimeProgram Setting
Temperature ControlPID Temperature Control with Heating, Isothermal Holding and Cooling (Fully Automatic Program Control)
DSC Range0～±600mW
DSC Resolution0.01uW
DSC Sensitivity0.001mW
Operating PowerAC220V/50Hz or custom
Atmosphere GasNitrogen, oxygen (automatic instrument switching)
Gas Flow0-300mL/min
Gas Pressure0.2MPa
Display24-bit color, 7-inch LCD touchscreen display
Data InterfaceStandard USB interface
StandardSupplied with Reference Materials (Indium, Tin, Lead) for User Temperature Calibration
Scan ModesHeating Scan, Cooling Scan, Isothermal Scan
Inquire Now
WKT-RC600YL DSC Differential Scanning Calorimeter Liquid Nitrogen Cooling WKT-RC600YL DSC Differential Scanning Calorimeter Liquid Nitrogen Cooling
Oxidation Induction Time (OIT), Glass Transition Temperature (Tg), Melting Point, Melting, Enthalpy Change, Phase Transition, Cold Crystallization, Crystallization, Product Stability, Degree of Cure, Degree of Crosslinking, Specific Heat Capacity, Heat of Reaction
-170℃-600℃
Liquid Nitrogen Cooling
Heating Scan, Cooling Scan, Isothermal Scan
Material No.: 2022098898017
Detailed Specifications
Temperature Range-170°C~600°C (Air Cooled)
Temperature Resolution0.001℃
Temperature Stability±0.01℃
Temperature Repeatability±0.1℃
Ramp Rate0.1～100℃/min
Cooling Rate 0.1~40℃/min
Stabilization TimeProgram Setting
Temperature ControlPID Temperature Control with Heating, Isothermal Holding and Cooling (Fully Automatic Program Control)
DSC Range0～±600mW
DSC Resolution0.01uW
DSC Sensitivity0.001mW
Operating PowerAC220V/50Hz or custom
Atmosphere GasNitrogen, oxygen (automatic instrument switching)
Gas Flow0-300mL/min
Gas Pressure≤5MPa
Program ControlSix-Segment Heating and Isothermal Control; Special Parameters Customizable
Display24-bit color, 7-inch LCD touchscreen display
Data InterfaceStandard USB interface
StandardSupplied with Reference Materials (Indium, Tin, Lead) for User Temperature Calibration
Scan ModesHeating Scan, Cooling Scan, Isothermal Scan
Inquire Now
WKT-RC1050 DSC Differential Scanning Calorimeter WKT-RC1050 DSC Differential Scanning Calorimeter
Oxidation Induction Time (OIT), Melting Point, Melting, Enthalpy Change, Phase Transition, Cold Crystallization, Product Stability, Heat of Reaction
Ambient to 1050°C; 1400°C Available on Request
Natural Cooling
Heating Scan, Cooling Scan, Isothermal Scan
Material No.: 2022098898018
Detailed Specifications
Temperature RangeAmbient to 1050°C (1400°C Customizable)
Temperature Resolution0.01℃
Temperature Stability±0.01℃
Temperature Repeatability±0.1℃
Ramp Rate0.1～100℃/min
Stabilization TimeProgram Setting
Temperature ControlPID Temperature Control with Heating, Isothermal Holding and Cooling (Fully Automatic Program Control)
DSC Range0～±600mW
DSC Resolution0.01uW
DSC Sensitivity0.001mW
Operating PowerAC220V/50Hz or custom
Atmosphere GasNitrogen, oxygen (automatic instrument switching)
Gas Flow0-300mL/min
Gas Pressure0.2MPa
Display24-bit color, 7-inch LCD touchscreen display
Data InterfaceStandard USB interface
StandardSupplied with reference materials (indium, tin) so users can calibrate the temperature themselves
Scan ModesHeating Scan, Cooling Scan, Isothermal Scan
Inquire Now
