| Model | WKT-400TC |
| Test Method | Mass Method (MFR) + Volume Method (MVR) |
| Printing | Automatic Print Output via Micro Thermal Printer |
| Extrusion and Discharge Section | Die diameter: Φ2.095±0.005 mm; die length: 8.000±0.025 mm |
| Barrel diameter: Φ9.550±0.025 mm; barrel length: 152±0.100 mm |
| Piston head diameter: 9.475±0.015 mm; piston head length: 6.350±0.100 mm |
| Standard Test Loads | Full set of weights, 8 levels in total |
| Level 1: 0.325kg = (piston rod + weight tray + heat-insulating sleeve + No. 1 weight body) = 3.187N |
| Level 2: 1.200kg (0.325kg + No. 2 0.875kg weight) = 11.77N |
| Level 3: 2.160kg = (0.325kg + No. 3 1.835kg weight) = 21.18N |
| Level 4: 3.800kg = (0.325kg + No. 4 3.475kg weight) = 37.26N |
| Level 5: 5.000kg = (0.325kg + No. 5 4.675kg weight) = 49.03N |
| Level 6: 10.000kg = (0.325kg + No. 5 4.675kg weight + No. 6 5.000kg weight) = 98.07N |
| Level 7: 12.500kg = (0.325kg + No. 5 4.675kg weight + No. 6 5.000kg weight + No. 7 2.500kg weight) = 122.58N |
| Level 8: 21.600 kg = (0.325kg + No. 2 0.875kg weight + No. 3 1.835kg weight + No. 4 3.475kg weight + No. 5 4.675kg weight + No. 6 5.000kg weight + No. 7 2.500kg weight + No. 8 2.915kg weight) = 211.82N |
| Temperature Range | Room temperature – 450℃ (500℃ optional) |
| Temperature Accuracy | ±0.2℃ |
| Display Resolution | 0.1℃ |
| Cutting Mode | Optional manual or automatic cutting |
| Temperature Recovery Time | Less than 4 min |
| Measuring Range | 0.1～300g／10min(MFR)、0.1～8000cm³/10min（MVR） |
| Timing Accuracy | 0.1s |
| Piston Displacement Accuracy | 0.01mm |
| Data Storage | 20 automatic mass-method and volume-method results |
| Display | Chinese LCD display, touch screen operation |
| Overall Dimensions | L 290 × W 410 × H 630 (mm) |
| Power Supply | AC220V ±10% 50HZ |
| Max Power | 600W |
